EMPI GTV-2 Stage 3 CNC Wedge Ported Heads | VW Type 1 94mm | 44/37.5mm SS Valves, 210 CFM, Pair (98-1437-B)

EMPI GTV-2 Stage 3 CNC Wedge Ported Heads — 94mm, 44/37.5mm SS Valves, 210 CFM, Pair (98-1437-B)

This is the top of the EMPI GTV-2 wedge-port range. The Stage 3 heads (98-1437-B) are CNC-machined to the maximum wedge port and cut for huge 44mm intake / 37.5mm exhaust Manley Race Master valves — they flow up to 210 CFM out of the box for serious bolt-on horsepower.

Machined for 94mm bore. Sold as a matched pair.

Vehicle Fitment

• VW Beetle: 1971-1979
• VW Bus: 1971-1979
• VW Karmann Ghia: 1971-1974
• VW Type 3: 1971-1973
• VW Thing: 1973-1975

Confirmed: VW Type 1 dual-port high-performance / racing builds running 94mm bore with high-lift, high-RPM cams — 1914cc, 2110cc, 2276cc, 2332cc. Not confirmed: stock 85.5mm or 90.5/92mm bore, single-port engines, Type 4 engines.

Why Choose EMPI?

The Stage 3 is EMPI's maximum-flow GTV-2 wedge head, cut on a 5-axis CNC mill for consistent porting and flowing up to 210 CFM.

Key Features & Benefits

• 94mm bore, GTV-2 dual port casting.
• Stage 3 wedge-port CNC machining: flows 210 CFM.
• 5-axis CNC mill: for repeatable, consistent porting.
• 44mm intake / 37.5mm exhaust stainless Manley Race Master valves.
• Dual hi-rev valve springs.
• Chromoly retainers and hardened Manley valve locks.
• Bronze valve guides.
• 64cc combustion chamber.
• 80cc intake volume / 75cc exhaust volume.
• Ports 20% larger than stock.
• Custom intake gasket included.
• 12mm 3/4" reach spark plug holes (recommend NGK DCPR8E).
• Rocker, exhaust, and intake studs included.
• Competition 3-angle valve job.
• Sold as a matched pair.

Technical Specifications

• Valves: 44mm intake / 37.5mm exhaust, stainless Manley Race Master
• Flow: 210 CFM @ .650" lift
• Combustion Chamber: 64cc
• Intake Volume: 80cc | Exhaust Volume: 75cc
• Port: Stage 3 CNC wedge
• Springs: dual hi-rev
• Part Number: 98-1437-B | UPC: 707924443905
• Sold as: matched pair

Frequently Asked Questions

• How much do they flow? Up to 210 CFM at .650" lift, out of the box.
• How is this different from the 98-1434-B Stage 3? This 98-1437-B uses 44/37.5mm valves; the 98-1434-B is the 42/37.5mm version.
• What bore are these for? 94mm pistons (1914-2332cc).
• Do I need lash caps? Yes — required with stainless valves, sold separately (00-4006-0).
• What's the part number? EMPI 98-1437-B (UPC 707924443905).
• Are you an authorized dealer? Yes.

Installation

Lash caps (P/N 00-4006-0) are required for all stainless steel valve applications — sold separately. 12mm long-reach spark plugs (NGK DCPR8E recommended) must be used in place of stock Bosch plugs. Verify rocker arm geometry and check for coil bind with dual springs.
