VW Beetle Bumper Bolts — EMPI Chrome, Long, Set of 4 (OE 113 707 191B) | Beetle thru 1967 (98-1013-0)
Couldn't load pickup availability
EMPI Chrome Bumper Bolts — Long, Set of 4 (98-1013-0)
Short answer: EMPI 98-1013-0 is a set of four long chrome carriage-style bumper bolts (OE 113 707 191B) for VW Beetle blade bumpers through the 1967 model year, front or rear. The square shoulder locks into the blade so the bolt doesn't spin, and the chrome domed head matches new blades. One set does one bumper; nuts are not included. M8 thread (dealer-listed).
Part numbers: EMPI 98-1013-0 (short 98-1013; bag 98-1013-B; 100-piece 98-1013-7). OE reference 113 707 191B / 113707191B / 113-707-191B. UPC 707924368352.
Vehicle Fitment
| Years | Vehicle | Notes |
|---|---|---|
| 1948–1967 | VW Beetle (Type 1) | Blade bumpers, front or rear; EMPI 98-1013-7 lists 12/1947–07/1967; dealers list 1952–1967 |
| Does not fit | 1968-and-later Beetle | Uses the short bolt, OE 113 707 191C / EMPI 98-1014-0 |
| Does not fit | Karmann Ghia (all) | Uses the short bolt |
| Not confirmed | Bus, Type 3, aftermarket or Euro bumpers | Different blade thickness |
Specifications
| Specification | Detail |
|---|---|
| Part number | EMPI 98-1013-0 |
| Type | Long carriage-style bumper bolt, chrome domed head |
| Thread | M8 (dealer-listed) |
| Quantity | Set of 4 (one bumper) |
| OE reference | 113 707 191B |
| UPC | 707924368352 |
| Country of origin | China |
| Shipping weight | 0.15 lb |
| Package dimensions | 6 x 5 x 1 in |
What's Included
Included:
- 4 long chrome carriage-style bumper bolts
Not included:
- Nuts (use 8mm nylock nuts and washers)
Why It Matters
Old bumper bolts rust, pit, or round off their square shoulders so they spin when you try to tighten the nut. The carriage-style shoulder locks into the square hole in the blade, and because the chrome domed head is the only part you see on the bumper face, new bolts finish the job instead of letting fresh blades down.
Installation Notes
- Soak the old nuts with penetrant a day ahead. Rusted bumper nuts usually have to be cut or split off. Don't twist the bracket.
- Seat the square shoulder fully in the blade before you snug the nut, and hold the head with a rag so you don't mar the chrome.
- Use 8mm nylock nuts and washers, and snug them evenly. Over-tightening dimples the chrome blade around the head.
- A dab of anti-seize on the threads makes the next removal easy.
Frequently Asked Questions
- Do the EMPI 98-1013-0 bumper bolts fit a 1965 VW Beetle? Yes. EMPI lists these long chrome bumper bolts for the Type 1 Beetle through the 1967 model year (OE 113 707 191B), front or rear bumper.
- Will long bumper bolts fit my 1970 Beetle? No. 1968-and-later Beetles, and Karmann Ghias, use the short bumper bolt (OE 113 707 191C, EMPI 98-1014-0).
- What is the OE number for pre-1968 VW Beetle bumper bolts? OE 113 707 191B. The EMPI set of 4 is 98-1013-0 (often listed as EMPI 98-1013), UPC 707924368352.
- How many bumper bolts do I need? Four bolts hold one blade bumper to its two brackets, so one set does one bumper. Order two sets to do front and rear.
- Are nuts included with the bumper bolts? No. The set is 4 bolts only. Use 8mm nylock nuts and washers.
