EMPI Universal Electric Windshield Washer Kit — 12V Pump in Clear Reservoir, with Hardware & Wiring | VW Beetle, Bus & Type 3 (15-2060-0)

EMPI Universal Electric Windshield Washer Kit — 12V (15-2060-0)

The stock VW washer runs on air from the spare tire. When the spare is low, the washer doesn't work, usually when you need it. EMPI 15-2060-0 replaces that with a 12-volt electric pump built into a see-through reservoir, with the mounting hardware and wiring included.

You press the switch and it sprays, and you can see the fluid level through the reservoir. It is a universal kit, so it goes into a Beetle, Bus, Type 3 or a 12-volt buggy without a model-specific bracket.

Key Features & Benefits

• 12V electric pump: sprays when you press the switch, whatever the spare tire pressure.
• Pump built into the reservoir: one unit to mount instead of a separate pump and tank.
• See-through reservoir: check the fluid level at a glance.
• Hardware and wiring included: everything you need to mount and wire it.
• Universal: suits Type 1, 2 and 3 VWs and 12-volt buggies.
• Genuine EMPI: sold by an authorized EMPI dealer.

Fitment

• CONFIRMED (EMPI): Universal design, and EMPI says it is ideally suited to VW Type 1, Type 2 and Type 3 on a 12-volt system.
• Dealer-listed (NOT CONFIRMED by EMPI): JBugs lists Beetle 1967–1977, Super Beetle 1971–1979, Karmann Ghia 1967–1974, Bus 1967–1979, Type 3 1967–1973 and Thing 1973–1974. Dealers also list dune buggies.
• NOT CONFIRMED: 6-volt cars (pre-1967 Beetle/Ghia/Bus) unless converted to 12V. Porsche applications.

Technical Specifications

• Part Number: EMPI 15-2060-0
• Voltage: 12V
• Pump: Electric, built into the reservoir
• Reservoir: See-through plastic (EMPI does not publish capacity)
• Includes: Mounting hardware and wiring (dealers also list a switch and instructions)
• Packaging: Skin pack
• UPC: 707924346435
• Country of Origin: Mexico
• Shipping Weight: 0.95 lb
• Package Dimensions: 18 x 12 x 2 in

Installation Notes

• Pick a mounting spot you can reach to fill it, away from the exhaust and hot engine parts. Under the front hood works well on a Bug or Ghia.
• Fuse the pump feed and use a momentary switch, so the pump never runs dry.
• Run the hose to your existing nozzles with no kinks. Test the spray before you close everything up.
• Use washer fluid, not plain water, if the car sees freezing weather. Ice will crack the reservoir and the pump.

Frequently Asked Questions

• Does this fit a 1967 VW Beetle? Yes, on a 12-volt car. 1967 was the first 12-volt Beetle year, and EMPI designed this universal kit for Type 1, 2 and 3 VWs.
• What is the part number? EMPI 15-2060-0 (often listed as EMPI 15-2060). UPC 707924346435.
• Does it work on a 6-volt car? No. The pump is 12-volt. A 6-volt car would need a 12-volt conversion or a different washer.
• What does it replace? The stock system uses tire pressure from the spare to push the fluid. This kit uses an electric pump in its own reservoir instead, so a low spare no longer means no washer.
• What is included? The 12V pump built into a see-through reservoir, mounting hardware and wiring. Some dealers also list a switch and instructions. Check what's in the pack when it arrives.
• Will it fit my dune buggy? Yes. It is a universal kit, so any 12-volt buggy with a windshield and nozzles can use it. Mount the reservoir where you can fill it and route the hose to your nozzles.
• How does it ship? As a normal parcel (0.95 lb, 18 x 12 x 2 in skin pack box). It is not hazmat and has no ground-only restriction. If EMPI is out of stock it can still be ordered and ships when EMPI restocks.
• Are you an authorized EMPI dealer? Yes. Washburn's Metal is an authorized EMPI dealer, and this is a genuine EMPI part shipped in EMPI packaging.
