EMPI GTV-2 Stage 1 CNC Wedge Ported Heads — 94mm, 40/35.5mm SS Valves, Pair (98-1431-B)

CNC-ported heads take the guesswork out of porting — every port cut the same, ready to bolt on. EMPI's GTV-2 Stage 1 wedge-port heads (98-1431-B) are machined on a 5-axis CNC mill for 94mm bore, with 40×35.5mm stainless Manley valves and dual hi-rev springs.

Stage 1 is the street/strip starting point in the CNC range, well-suited to 1914–2110cc builds. Sold as a matched pair.

Vehicle Fitment

• VW Beetle: 1971-1979
• VW Bus: 1971-1979
• VW Karmann Ghia: 1971-1974
• VW Type 3: 1971-1973
• VW Thing: 1973-1975

Confirmed: VW Type 1 dual-port big-bore builds running 94mm bore — 1914cc, 2110cc, 2276cc. Not confirmed: stock 85.5mm or 90.5/92mm bore (use the matching-bore CNC head), single-port engines, Type 4 engines.

Why Choose EMPI?

EMPI's GTV-2 CNC heads are cut on a 5-axis mill for consistent, repeatable porting.

Key Features & Benefits

• 94mm bore, GTV-2 dual port casting.
• Stage 1 wedge-port CNC machining: cut on a 5-axis CNC mill.
• 40mm intake / 35.5mm exhaust stainless Manley valves.
• Dual hi-rev valve springs.
• Chromoly retainers and hardened keepers.
• Bronze valve guides.
• Custom intake gasket included.
• 12mm 3/4" reach spark plug holes.
• Rocker, exhaust, and intake studs included.
• Performance 3-angle valve job.
• Sold as a matched pair.

Technical Specifications

• Valves: 40mm intake / 35.5mm exhaust, stainless Manley
• Springs: dual hi-rev
• Port: Stage 1 CNC wedge
• Spark plugs: 12mm 3/4" reach
• Part Number: 98-1431-B | UPC: 707924443844
• Sold as: matched pair

Frequently Asked Questions

• What does CNC porting get me? Consistent, repeatable port work cut on a 5-axis mill — ready to bolt on, no hand porting needed.
• What bore are these for? 94mm pistons (1914-2276cc).
• How does Stage 1 compare to Stage 3? Stage 1 is the street/strip port; Stage 3 has larger valves and a more aggressive wedge port for maximum flow.
• Sold each or as a pair? Matched pair.
• What's the part number? EMPI 98-1431-B (UPC 707924443844).
• Are you an authorized dealer? Yes.

Installation

Lash caps (P/N 00-4006-0) are required for all stainless steel valve applications — sold separately. 12mm long-reach spark plugs must be used in place of stock Bosch plugs. Verify rocker arm geometry and check for coil bind with dual springs.
