EMPI Hi-Performance Dual Port Cylinder Head — 94mm Bore, Stainless Valves, 3-Angle Valve Job (98-1375-B)

Big-bore 94mm builds need heads cut to match, and these are the stainless-valve answer short of a full race head. EMPI's Hi-Performance dual-port head (98-1375-B) is the proven 98-1355-B casting machined for 94mm pistons, with stainless Manley valves, hi-rev springs, chromoly retainers, bronze guides, and a 3-angle valve job. SCORE-approved, sold each.

Vehicle Fitment

• VW Beetle: dual-port big-bore builds, 94mm (1914cc / 2110cc / 2276cc)
• VW Bus: dual-port big-bore builds
• VW Karmann Ghia: dual-port big-bore builds
• VW Type 3: dual-port big-bore builds
• VW Thing: dual-port big-bore builds

Not confirmed: stock 85.5mm or 90.5/92mm bore (use the matching-bore head), single-port engines, Type 4 engines.

Why Choose EMPI?

You get genuine parts backed by real support.

Key Features & Benefits

• Machined for 94mm: direct fit for 1914cc, 2110cc, and 2276cc builds.
• Stainless Manley valves: 35.5mm intake / 32mm exhaust.
• Upgraded valvetrain: hi-rev single valve springs, chromoly retainers, and hardened keepers.
• Bronze valve guides: for durability.
• 3-angle performance valve job: improved flow.
• Special aluminum alloy: fully repairable.
• Race-ready: SCORE approved for Class 11 competition.
• Sold each.

Technical Specifications

• Bore: 94mm, dual port casting (98-1355-B based)
• Valves: 35.5mm intake / 32mm exhaust, stainless Manley
• Chamber Volume: 51cc
• Intake Port Volume: 53cc
• Exhaust Port Volume: 56.5cc
• Spark plugs: 14mm x 1/2"
• Part Number: 98-1375-B (UPC 707924472363)

Important: Lash caps (P/N 00-4006-0) are required for all stainless steel valve applications — sold separately.

Frequently Asked Questions

• What bore are these machined for? 94mm pistons.
• What displacements? 1914cc, 2110cc, and 2276cc big-bore/stroker builds.
• Do I need lash caps? Yes — required with stainless valves, sold separately (00-4006-0).
• Sold each or as a pair? Each.
• What's the part number? EMPI 98-1375-B (UPC 707924472363).
• Are you an authorized dealer? Yes.
